适用范围及功能

主要适用于固体绝缘材料（如：塑料、橡胶、层压材料、薄膜、树脂、云母、陶瓷、玻璃、绝缘漆等绝缘材料及绝缘件）在工频电压或直流电压下击穿强度和耐电压的测试。

本仪器由电脑控制，是我公司自主研发的全新第二代介电击穿检测仪器，本仪器电子控制系统是通过西门子PLC控制，数据采集方式通过光电隔离，有效解决试验过程中的抗干扰问题，软件操作使用方便，能够实时显示动态曲线，同时升压速率无级可调，可以根据自己的需要进行升压速率调节，调节范围在10V-5000V/S，处于国内领地位（国内*能达到此功能的厂家），使升压速率真正做到匀速、准确，并能够准确测出漏电电流的数据。可实时绘制试验曲线，显示试验数据，判断准确，并可保存，分析，打印试验数据。

This instrument is controlled by computer, is our company independent research and development of the new second generation of dielectric breakdown detection instrument, the instrument electronic control system is controlled by Siemens PLC, data acquisition through photoelectric isolation, effectively solve the anti-interference problem in the test process, software operation is convenient to use, can display the dynamic curve in real time, while the boost rate is steplessly adjustable, according to their own needs for boost rate adjustment, the adjustment range is 10V-5000V/S, in the domestic leading position (domestic * Manufacturers who can achieve this function), so that the boost rate is truly uniform, accurate, and can accurately measure the leakage current data. Test curves can be drawn in real time, test data displayed, accurate judgment, and can be saved, analyzed, and printed test data.
